Hikvision Keypad module with backlight, input pin code to open door, call indoor station via inputting room number, powered by other module.
Model: DS-KD-DIS
KD8 Series Pro Modular Door Station
- Modular door station Display module needs mounting bracket
- 3.5 inch LCD screen, 4 buttons, backlight, IP65
- Dial number display, pin code unlock, contact list display
- Up to 2000 contacts can be added to the device
- Stores and searches contact list
- Multiple languages
Specifications
- Button: 4( Up, Down, OK, Back)
- Installation: Flush mounting, surface mounting
- Protective Level: IP65
- Working Temperature: 20 C to 60 C(-4 F to 140 F)
- Working Humidity: 10% to 95%
- Dimensions: 98.5 mm 100 mm 34.2 mm (3.87" 3.95" 1.33")
- Application Environments: Outdoor
- Power Consumption: 2.5 W
